 Posted - May 18 2008 : 11:18:12 AM
|
I finally got my new board up on legs, and running. As seen in the photo, it's a sort of inverted figure eight, with 2 passing sidings (one on right not completed yet). There is also a connection track in the upper left, and will eventually be one on the lower right. I put the whole thing on casters, for easy movement around the garage. It has 18" radius curves, with 22" on the upper right and lower left to let the trains "stretch their legs" a bit. Check out the next reply to see the control panel.
|
Country:  USA ~
Posts: 874 ~
Member Since: October 15 2007 ~
Last Visit: June 09 2019
|
Alert Moderator
|
|
|
|
Posted - May 18 2008 : 11:23:08 AM
|
Here is the control panel--I used a strip of aluminum, painted clear to avoid oxidation. I taped off the schematic, "painting" it with a wide permanent marker. Turnouts are operated with red and black momentary contact buttons, and blocks are controlled with SPDT toggles, that will enable two cabs to operate separately.
|
|
Country: USA ~
Posts: 874 ~
Member Since: October 15 2007 ~
Last Visit: June 09 2019
|
Alert Moderator
|
|
|
|
Posted - May 18 2008 : 12:05:31 PM
|
| looking very good,well thought out,keep us posted ken
|
Country:  United Kingdom ~
Posts: 8294 ~
Member Since: September 28 2006 ~
Last Visit: October 20 2021
|
Alert Moderator
|
|
|
|
Posted - May 18 2008 : 5:30:53 PM
|
| Looks great.
|
|
Country: USA ~
Posts: 2507 ~
Member Since: January 31 2006 ~
Last Visit: October 21 2017
|
Alert Moderator
|
|
|
|
Posted - May 19 2008 : 03:40:18 AM
|
Hey,
Nice work! I like the control panel.
Mike
|
|
Country: USA ~
Posts: 790 ~
Member Since: April 30 2006 ~
Last Visit: July 21 2015
|
Alert Moderator
|
|
|
|
Posted - May 19 2008 : 10:41:15 PM
|
| Nice benchwork there. I appreciate the control panel; I would like to do something like that but I don't have the patience. Atlas modules got me up and running quickly. But I did add some custom switches for Analog / DCC conversion and the like.
|
|
Country: USA ~
Posts: 2175 ~
Member Since: July 15 2006 ~
Last Visit: January 31 2010
|
Alert Moderator
|
|
|
|
 Posted - May 19 2008 : 11:32:21 PM
|
I like the integrated control panel, too. Well done!
The Tyco Depot
|
|
Country: USA ~
Posts: 3927 ~
Member Since: June 20 2007 ~
Last Visit: November 19 2015
|
Alert Moderator
|
|
|
|
Posted - June 14 2008 : 2:11:00 PM
|
Hello All--Time for an update on my 'new' layout...the one seen above on this topic. As much as a liked the idea of 2 passing sidings, a diamond crossing, and the really cool control panel I made, It couldn't do what I wanted, i.e. have a solid run with 22" minumum radius, not short out my new British models with wide wheels, and be able to operate in a somewhat realistic manner (besides watching 2 trains pass). So, simpler, but better, I think. You can see that I have an outer loop of 22" radius. A switch leads off the main (left rear of photo) to give a connection to the rest of the world. The inner loop (the branch line) connects to the outer via a crossover. On the back side of the branch is an electric switch which will lead to a mine or something. With careful placement of insulated joiners and use of Peco power-routing switches, I do not need any block wiring or electrical switches. At least 2 locos can be on the table at once, and either can get to any spot on the layout. Generally, freight can be brought from the outer spur to the branch, and a passenger train can run the outer main, dropping off cars for the branch loco at the crossover. I have only set down some temporary scenery so far. Notice the holes in the front fascia (sob..) where I removed the control panel.
|
|
Country: USA ~
Posts: 874 ~
Member Since: October 15 2007 ~
Last Visit: June 09 2019
|
Alert Moderator
|
|
|
|
Posted - June 14 2008 : 3:04:14 PM
|
Looks real nice so far. Well done..
-Gareth
|
Country:  Canada ~
Posts: 4200 ~
Member Since: January 08 2006 ~
Last Visit: November 09 2021
|
Alert Moderator
|
|
|
|
Posted - June 14 2008 : 3:32:36 PM
|
Lookin good, keep it going.
Cheers
Bill
|
|
Country: USA ~
Posts: 122 ~
Member Since: May 17 2008 ~
Last Visit: July 29 2019
|
